Install
Install operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of log information (000000 to 999999)
Detailed Information
Detailed information displays for this operation, as shown in the following table.
Table 63 Detailed information for Install operation (installing additional channel adapters)
DescriptionItem
The channel adapter (CHA). mounting location.Channel Adapter (CHA)
The kind of PCB mounted.Kind
The speed mode of the Fibre PCB is indicated for open systems.Fibre Pcb
<Standard>: Standard mode. <High Speed/MIX>: High speed
mode/Mix mode.
Mode(Block-A/
Block-B/Block-
C/Block-D)
The mounting location of the port.Port
The type of Initiator or Target.Initiator/Target
The channel speed is indicated for open systems. 1: 1 Gbps, 2: 2
Gbps, 4: 4 Gbps, Auto: Auto mode.
Channel Speed
Indicates the range of the CU number which the port belongs.CU Number
The number of ports.Num of Ports
The HTP is indicated for FICON.HTP
The LCP or RCP is indicated for ESCON.LCP/RCP
The emulation type is indicated for mainframe systems.Emulation
The number of Channel Adapter (CHA)s.Num. of Channel Adapter (CHA)s
Example 2 (Installing additional storage systems, ECC groups or LDEVs)
user-name,xx,YYYY/MM/DD,HH:MM:SS:xxx, 00:00,[Install],Install,,Normal end,Seq.=xxxxx
+DKA=[DKA-1B,DKA-2N],Num. of DKAs=2
+{DKU,AC-BOX}=[{DKU-R1,3-Phase},{DKU-R2,3-Phase}],Num. of DKUs=2
+FSW=[FSWR10-RL,FSWR10-RU],Num. of FSWs=2
+{DKU,PDU}=[{DKU-RK1,HITACHI Original},{DKU-RK2,Others}],Num. of DKUs=2
+{PG,RAID Level,Drive Type,Emulation,Concatenation}={3-1,RAID1 (2D+2D),DKR2F-J300FC,
OPEN-V,3-1/3-2},
++{CU:LEDV,Emulation,Size,Unit,SSID}=[{0x03:0x40,,1125767168,LBA,0x0007}],Num. of LDEVs=1
+{PG,RAID Level,Drive Type,Emulation,Concatenation}={3-2,RAID1 (2D+2D),DKR2F-J300FC,
OPEN-V,3-1/3-2},
++{CU:LEDV,Emulation,Size,Unit,SSID}=[{0x03:0x41,,1125767168,LBA,0x0007}],Num. of LDEVs=1
+{PG,RAID Level,Drive Type,Emulation,Concatenation}={3-3,RAID1 (2D+2D),DKR2F-J300FC,
OPEN-V,-},
++{CU:LEDV,Emulation,Size,Unit,SSID}=[{0x03:0x42,,1125767168,LBA,0x0007}],Num. of LDEVs=1
Install function102
