18 Preparing for External Storage XP operations
SANRISE9900V series subsystem • “SANRISE99xxV series subsystem” indicates the
SANRISE9970V and SANRISE9980V.
• In this user guide, the arrays appear as
“SANRISE9900V subsystem”.
• In External Storage XP panes, the arrays appear as
“9970V” and “9980V”, respectively.
• Alternate paths are in Multi mode.
SANRISE9500V series subsystem • “SANRISE95xxV series subsystem” indicates the
SANRISE9530V, SANRISE9570V, and
SANRISE9580V.
• In this user guide, the arrays appear as
“SANRISE9500V subsystem”.
• In External Storage XP panes, the arrays appear as
“9500V”.
• Alternate paths are in Single mode.
SANRISE2000 series subsystem • “SANRISE2000 series subsystem” indicates the
SANRISE2200 and SANRISE2800.
• In this user guide, the arrays appear as
“SANRISE2000 subsystem”.
• In External Storage XP panes, the SANRISE2200
appears as “0401”, and the SANRISE2800
appears as “0400”.
• Alternate paths are in Multi mode.
SANRISE H12000 subsystem • In External Storage XP panes, the array appears as
“12000”.
• Alternate paths are in Multi mode.
SANRISE H10000 subsystem • In External Storage XP panes, the array appears as
“10000”.
• Alternate paths are in Multi mode.
SANRISE H1024/H128 subsystem • In External Storage XP panes, the arrays appear as
“1024” and “128”, respectively.
• Alternate paths are in Multi mode.
SANRISE H512/H48 subsystem • In External Storage XP panes, the arrays appear as
“512” and “48”, respectively.
• Alternate paths are in Multi mode.
SANRISE H256 subsystem • In External Storage XP panes, the array appears as
“256”.
• Alternate paths are in Multi mode.
IBM Storage Subsystem For specific supported storage arrays, contact your
HP account support representative.
EMC Storage Subsystem For specific supported storage arrays, contact your
HP account support representative.
Fujitsu Storage Subsystem For specific supported storage arrays, contact your
HP account support representative.
NEC Storage Subsystem For specific supported storage arrays, contact your
HP account support representative.
Table 2 Storage arrays that can be connected as external arrays (continued)
Storage array Notes
