External Storage XP user guide 17
Lightning 9900V series subsystem • “Lightning 99xxV series subsystem” indicates the
Lightning 9970V and Lightning 9980V.
• In this user guide, the arrays appear as “Lightning
9900V subsystem”.
• In External Storage XP panes, the arrays appear as
“9970V” and “9980V”, respectively.
• Alternate paths are in Multi mode.
Thunder 9500V series subsystem • “Thunder 95xxV series subsystem” indicates the
Thunder 9530V, Thunder 9570V, and Thunder
9580V.
• In this user guide, the arrays appear as “Thunder
9500V subsystem”.
• In External Storage XP panes, the arrays appear as
“9500V”.
• Alternate paths are in Single mode.
Lightning 9900C series subsystem • “Lightning 99xxC series subsystem” indicates the
Lightning 9910 and Lightning 9960.
• In this user guide, the arrays appear as “Lightning
9900 subsystem”.
• In External Storage XP panes, the Lightning 9910
appears as “0401”, and the Lightning 9960
appears as “0400”.
• Alternate paths are in Multi mode.
A/H-6593 subsystem • In External Storage XP panes, the array appears as
“300”.
• Alternate paths are in Multi mode.
SANRISE Universal Storage Platform subsystem • In this user guide, the array appears as “SANRISE
USP subsystem”.
• In External Storage XP panes, the array appears as
“USP”.
• Alternate paths are in Multi mode.
SANRISE Network Storage Controller subsystem • In this user guide, the array appears as “SANRISE
NSC subsystem”.
• In External Storage XP panes, the array appears as
“NSC”.
• Alternate paths are in Multi mode.
SANRISE Adaptable Modular Storage subsystem • In this user guide, the array appears as “SANRISE
AMS subsystem”.
• In External Storage XP panes, the array appears as
“AMS”.
• Alternate paths are in Single mode.
SANRISE Workgroup Modular Storage • In this user guide, the array appears as “SANRISE
WMS subsystem”.
• In External Storage XP panes, the array appears as
“WMS”.
• Alternate paths are in Single mode.
Table 2 Storage arrays that can be connected as external arrays (continued)
Storage array Notes
