16 Preparing for External Storage XP operations
HP StorageWorks XP1024/XP128 Disk Array • In External Storage XP panes, the arrays appear as
“1024” and “128”, respectively.
• Alternate paths are in Multi mode.
HP StorageWorks XP512/XP48 Disk Array • In External Storage XP panes, the arrays appear as
“512” and “48”, respectively.
• Alternate paths are in Multi mode.
HP StorageWorks XP256 Disk Array • In External Storage XP panes, the array appears as
“256”.
• Alternate paths are in Multi mode.
HP StorageWorks 200 Storage Virtualization System • In External Storage XP panes, the array appears as
“SVS200”.
• Alternate paths are in Multi mode.
HP StorageWorks 3000/5000 Enterprise Virtual Array
(Active/Standby and Active/Active controllers) or
HP StorageWorks 4000/6000/8000 Enterprise Virtual
Array (Active/Active controllers)
• In this user guide, the arrays appear as “EVA
array”.
• In External Storage XP panes, the arrays appear as
“EVA”.
• Alternate paths are in Single mode (meaning that
dynamic load balancing across multiple active paths
is not enabled).
HP StorageWorks MSA1000/1500 (Active/Standby) • In this user guide, the arrays appear as “MSA
array”.
• In External Storage XP panes, the arrays appear as
“MSA”.
• Alternate paths are in Single mode.
TagmaStore™ Universal Storage Platform subsystem • In this user guide, the array appears as
“TagmaStore™ USP subsystem”.
• In External Storage XP panes, the array appears as
“USP”.
• Alternate paths are in Multi mode.
TagmaStore™ Network Storage Controller subsystem • In this user guide, the array appears as
“TagmaStore™ NSC subsystem”.
• In External Storage XP panes, the array appears as
“NSC”.
• Alternate paths are in Multi mode.
TagmaStore™ Adaptable Modular Storage subsystem • In this user guide, the array appears as
“TagmaStore™ AMS subsystem”.
• In External Storage XP panes, the array appears as
“AMS”.
• Alternate paths are in Single mode.
TagmaStore™ Workgroup Modular Storage subsystem • In this user guide, the array appears as
“TagmaStore™ WMS subsystem”.
• In External Storage XP panes, the array appears as
“NSC”.
• Alternate paths are in Single mode.
Table 2 Storage arrays that can be connected as external arrays (continued)
Storage array Notes
