Table 27 lists the base LDEV capacity, minimum LDEV capacity, maximum external LU capacity, and
number of LDEVs that can be defined for the external LU with maximum capacity. For the OPEN-L
emulation type, the base LDEV capacity and the minimum LDEV capacity are the same because CVs
cannot be created. For the OPEN-V emulation type, the base LDEV capacity is not listed because there is
no concept of the base LDEV capacity.
3380-KA 72,000 3,823,200 10,080
3380-KB 72,000 3,823,200 10,080
3380-KC 72,000 3,823,200 10,080
3390-3 87,000 5,809,860 10,440
3390-3A 87,000 5,809,860 10,440
3390-3B 87,000 5,809,860 10,440
3390-3C 87,000 5,809,860 10,440
3390-3R 87,000 5,809,860 10,440
3390-9 87,000 17,429,580 43,500
3390-9A 87,000 17,429,580 43,500
3390-9B 87,000 17,429,580 43,500
3390-9C 87,000 17,429,580 43,500
3390-L 87,000 57,002,400 40,020
3390-LA 87,000 57,002,400 40,020
3390-LB 87,000 57,002,400 40,020
3390-LC 87,000 57,002,400 40,020
3390-M 87,000 114,004,800 92,220
3390-MA 87,000 114,004,800 92,220
3390-MB 87,000 114,004,800 92,220
3390-MC 87,000 114,004,800 92,220
OPEN-3 72,000 4,806,720 11,520
OPEN-8 72,000 14,351,040 38,880
OPEN-9 72,000 14,423,040 38,880
OPEN-E 72,000 28,452,960 27,360
OPEN-L 71,192,160 71,192,160 10,080
OPEN-V 96,000 – 0
Table 26 LDEV capacity information for each emulation type (continued)
Emulation type Minimum data area
capacity (blocks)
Base data area
capacity (blocks)
Control information
area capacity (blocks)
