External Storage XP user guide 131
NOTE: When connecting to a TagmaStore AMS or TagmaStore WMS subsystem, use LUN Manager to
set the data transfer speed of the XP12000/XP10000/SVS200 external port you use to a fixed value
other than Auto Negotiation. Also, set the data transfer speed of the target port of the TagmaStore AMS or
TagmaStore WMS subsystem to the same fixed value according to the data transfer speed of the external
port.
NOTE: You can either specify or omit any other parameters.
Table 17 System parameter settings (TagmaStore AMS and TagmaStore WMS subsystems)
Pane name Parameters Parameter setting
Boot Options Start Attribute
• Single Mode Specify this parameter when the TagmaStore
AMS or TagmaStore WMS subsystem is in
the one-controller configuration.
• Dual Active Mode Specify this parameter when the TagmaStore
AMS or TagmaStore WMS subsystem is in
the two-controller configuration.
Delay Planned Shutdown You can either specify this parameter or omit
specifying this parameter.
Drive blocking mode You can either specify this parameter or omit
specifying this parameter.
Vendor ID Keep this parameter as HITACHI (default),
and do not change.
Product ID Keep this parameter as DF600F (default),
and do not change.
ROM Microprogram Version You can either specify this parameter or omit
specifying this parameter.
RAM Microprogram Version You can either specify this parameter or omit
specifying this parameter.
System Parameter Option You can either specify this parameter or omit
specifying this parameter.
Operation if the processor failure occurs Set this parameter to Reset of occurred.
WEB Title You can either specify this parameter or omit
specifying this parameter.
Write and verify mode Set this parameter to ON.
Port Options Port Option You can either specify this parameter or omit
specifying this parameter.
Host Connection
Mode
Host Connection Mode 1 Set this parameter to Standard Mode.
Host Connection Mode 2 Do not specify any parameters.
NOTE: Do not specify HISUP OFF mode,
either.
