External Storage XP user guide 129
Relationship between serial numbers in the Device list on the LU Operation pane
and Thunder 9500V subsystem models
When the external array is a Thunder 9500V subsystem, you can identify the subsystem model from the
serial number displayed in the Serial column in the Device list on the LU Operation pane.
Table 14 shows the relationship between serial numbers displayed in the Serial column and subsystem
models.
NOTE: In serial numbers, X is an arbitrary number or character.
Relationship between the WWN of the port on the Thunder 9500V subsystem and
the controller
When the external array is a Thunder 9500V subsystem, you can identify the controller (controller 0 or
controller 1) from the port’s WWN.
Table 15 shows the relationship between the port’s WWN and the controller.
NOTE: In WWNs, X is an arbitrary number or character. Ports in the same apparatus have identical
values.
Table 14 Relationship between serial numbers and subsystem models (Thunder 9500V subsystems)
Displayed serial number Model
D600XXXX 9570V, 9520V
D60JXXXX 9530V
D60HXXXX 9580V, 9585V
Table 15 Relationship between ports’ WWNs and controllers (Thunder 9500V subsystems)
Model Controller Port’s WWN
9570V
9530V
9520V
Controller 0 XXXXXXXXXXXXXXX0
XXXXXXXXXXXXXXX1
Controller 1 XXXXXXXXXXXXXXX2
XXXXXXXXXXXXXXX3
9580V
9585V
Controller 0 XXXXXXXXXXXXXXX0
XXXXXXXXXXXXXXX1
XXXXXXXXXXXXXXX2
XXXXXXXXXXXXXXX3
Controller 1 XXXXXXXXXXXXXXX4
XXXXXXXXXXXXXXX5
XXXXXXXXXXXXXXX6
XXXXXXXXXXXXXXX7
