External Storage XP user guide 123
Busy Status: The external array’s status is BUSY.
Corrective action: The external array’s port is still
recognized. Check the external array’s settings and
the load on the external array (for example, check
whether the configuration assigns too much load on
the external array). If you cannot restore the path,
contact your HP account support representative.
LDEV reserved Status: The external array’s status is Reserved. You
cannot access the external array’s device from the
local array.
Corrective action: Remove the Reserve status on the
external array’s device.
Response error Status: The external array’s status is Blocked due to
an abnormal reply (Response). You might not be
able to access the external array’s device, or data
protection might be set on the external array’s
device.
Corrective action: The external array’s port is
recognized. Check the external array’s setting and
status. If you cannot restore the path, contact your
HP account support representative.
Initiator port Status: The external array (for example, XP) port
attribute changed to Initiator.
Corrective action: Set the external array’s port
attribute back to target. If you cannot restore the
path, contact your HP account support
representative.
RCU target port Status: The port attribute of the external array
changed to RCU target.
Corrective action: Set the port attribute of the
external array to Target. If you cannot restore the
path, contact your HP account support
representative.
Unknown port Status: The external array’s port attribute is
unknown.
Corrective action: The external array’s port is
recognized. Check the condition of the connection
(for example, cables and switches) to the external
array. If you cannot restore the path, contact your
HP account support representative.
Table 12 General External Storage XP troubleshooting (continued)
Error Corrective action
