HP Hitachi ShadowImage for Mainframe User Guide (T5213-96032, November 2011)

Table 27 CTG Window (continued)
DescriptionItem
Applies the SIz operations displayed in the CTG List to the XP24000/XP20000 storage
system.
Apply button
Cancels all the ongoing operations specified in the CTG List without applying them to
the XP24000/XP20000 storage system.
Cancel button
To perform a CTG operation, use the desired command selected from the menu that can be
displayed by right-clicking one of the CTGs displayed in the CTG List that you want to work on.
Table 28 (page 60) shows the available menu commands in the CTG List.
Table 28 ShadowImage for Mainframe Menu Commands for the CTG List
FeatureCommand
Select this command when you want to reserve a free CTG. When you select this
command, the new CTG will be ready to be added. Note that this command will remain
dimmed when you open the menu by right-clicking a CTG whose status is not set to Free.
Add CT Group
Select this command when you want to change the status of a reserved CTG to Free.
When you select this command, the CTG will be ready to change its status of unused
Delete CT Group
CTG. Note that this command will remain dimmed when you open the menu by
right-clicking a CTG whose status is already set to Free.
Select this command when you want to display the information for a pair or pairs
registered in the selected CTG. When you select this command, the CT Group Status
CT Group Status
dialog box opens. Note that this command will remain dimmed when you open the menu
by right-clicking a CTG whose status is set either to Reserved or Free.
Select this command when you want to display the error information for the CTG operation
that failed. Note that this command will remain dimmed when there is no error.
Error Detail
NOTE: For the list of SIz error codes and corrective actions, see the HP
XP24000/XP20000 Remote Web Console User's Guide.
60 Using the ShadowImage for Mainframe GUI
