Figure 26 Option Window
Table 26 Option Window
DescriptionItem
Enables an option name when you check the check box of an option name. If you clear
the check box, that option will be disabled. Note that only options that are available for
Select Option(s) box
SIz in this box are Swap & Freeze and HOST I/O Performance. FCv2 Slower Copy1 and
FCv2 Slower Copy2 are the options for FlashCopy Mirroring V2. See the HP
XP24000/XP20000 for FlashCopy Mirroring Software User's Guide for detailed
information about these options.
Even if you have selected the check boxes of other option names, they will not be enabled.
Applies the SIz options checked in the Select Option(s) box to the storage system.Apply button
Cancels all the options set in the Select Option(s) box.Cancel button
CTG Window
The CTG window (see Figure 27 (page 59)) displays the information for the selected CTGs
(abbreviated hereafter to CTG or CT Group where applicable) that are either registered or not
used.
58 Using the ShadowImage for Mainframe GUI
