Table 24 History Window
DescriptionItem
Allows you to return to the previous page of the list. This button is selectable only when
the number of operation histories in the storage system exceeds 16,384, which is the
Previous button
maximum number of histories that can be displayed on one page. The button is grayed
out if the total number of operation histories in the storage system is less than 16,384.
Allows you to turn to the next page of the list. This button is selectable only when the
number of operation histories in the storage system exceeds 16,384 volumes, which is
Next button
the maximum number of histories that can be displayed on one page. The button is
grayed out if the total number of operation histories in the storage system is less than
16,384.
Displays the date and time (YYYY/MM/DD hour/min/sec) when a SIz pair or volume
operation has been performed.
Date
Displays the LDKC:CU:LDEV of the S-VOLs used for pair operation in the past.S-VOL
Displays the LDKC:CU:LDEV of the T-VOLs used for pair operation in the past.T-VOL
Displays the reference codes of ShadowImage for Mainframe.Code
Displays the messages to inform the conditions of the past SIz pair. For details about the
messages, see Table 25 (page 57).
Message
Table 25 ShadowImage for Mainframe Status & History Reference Codes and Messages
DescriptionMessageCode
The SIz initial copy operation started.DUPLEX START4710
The SIz initial copy operation ended, and the
pair status changed to Duplex.
DUPLEX END4720
The SIz split operation started.SPLIT START4730
The SIz split operation ended, and the pair
status changed to Split.
SPLIT END4740
The SIz resync operation started.RESYNC START4750
RESYNC-R START
The SIz resync operation ended, and the pair
status changed to Duplex.
RESYNC END
RESYNC-R END
4760
The SIz pair is deleted, and the pair status
changed to Simplex.
PAIR DELETE4780
The SIz pair suspended, and the pair status
changed to Suspend.
PAIR SUSPEND4790
A copy ended abnormally (reason other than
above).
PENDING ABNORMAL END47D0
Initialization started.INITIALIZE START47E9
Initialization ended normally.INITIALIZE END47EA
Initialization ended abnormally.INITIALIZE ENDED ABNORMAL47EB
Option Window
You can set options for ShadowImage for Mainframe in the Option window (see Figure 26 (page
58)). For detailed information about how to set options, see (page 66).
Option Window 57
