Table 23 ShadowImage for Mainframe Menu Commands for the Preview List
FeatureCommand
Cancels the selected settings. If you perform this command, the selected settings will be
cleared.
Delete
Allows you to change the setting of the selected operation. This command becomes
accessible only when the item you select from the Preview List is set to Add Pair, Split
Pair or Resync Pair operation.
Modify
Displays the error message box, which displays the error code and message. For the
SIz error codes, see the HP XP24000/XP20000 Remote Web Console User's Guide.
Error Detail
History Window
The History window (see Figure 25 (page 56)) displays the past record of pair and relationship
operations. For information about how to look up the operation history, see (page 86).
An S-VOL or T-VOL LDEV number that ends with a pound or gate symbol (#) mark indicates that
the LDEV is an external volume (for example, 00:00:01 #). For details about the external volumes,
see the HP XP24000/XP20000 External Storage Software User's Guide.
An S-VOL LDEV number that ends with the letter M indicates that the LDEV is a migration volume
(for example, 00:00:01 M).
The upper area of the History window lists the operation history of SIz pairs and Version 1
relationships, and the lower area of the window lists the operation history of Version 2 relationships.
For details about the operation history of Version 1 and Version 2 relationships, see the HP
XP24000/XP20000 for FlashCopy Mirroring Software User's Guide.
Figure 25 History Window
56 Using the ShadowImage for Mainframe GUI
