Table 47 Contents that Display when Issuing the CQUERY or the QUERY Command on SIz Pairs
(continued)
ContentItem
Serial number of the T-VOL. If you perform the CQUERY TSO command for the
T-VOL, the following information is displayed as well as the serial number of
the T-VOL.
SECONDARY-SERIAL
00ab000nnnnn
a:
• S: This pair is defined as a CTG.
• 0: Other than listed above.
b:
• @: This pair was split by using the At-Time Split function.
• 0: Other than listed above.
nnnnn: Serial number of the T-VOL.
Since this item is invalid for SIz pairs, 1 is always displayed.
1
PATHS
Since this item is invalid for SIz pairs, FFFF FFFF is always displayed.
1
SAID DEST STATUS
Since this item is invalid for SIz pairs, PATH ESTABLISH is always displayed.
1
DESCRIPTION
Since this item is invalid for SIz pairs, 100% is always displayed.
1
PERCENT OF COPY COMPLETE
Since this item is invalid for SIz pairs, the content of this item is also invalid.SUBSYSTEM
Since this item is invalid for SIz pairs, the content of this item is also invalid.WWN
Since this item is invalid for SIz pairs, the content of this item is also invalid.LIC LEVEL
1
When the MCU-RCU path for TCz is created on the CU where the SIz pair is created, the information about the MCU-RCU
path will be displayed. For detailed information about the MCU-RCU path, see the HP XP24000/XP20000 Continuous
Access Software User's Guide.
CQUERY
Table 48 (page 103) lists and describes the CQUERY command parameters that can be used when
you see the status of SIz pairs.
Table 48 CQUERY Command Parameters
ValueParameter
Device number.DEVN
Figure 48 (page 104) shows an example of the CQUERY command.
Displaying Pair Status Using PPRC Commands 103
