Reference Architecture| Ceph on HP ProLiant SL4540 Gen8 Servers

Install Ceph Software

This step pulls down the Ceph distribution packages and installs onto all cluster role servers.

If using ceph-deploy to install Ceph packages and using a proxy server to get to the internet, edit wgetrc’s proxy

configuration under all Ubuntu nodes. Otherwise, ‘ceph-deploy install’ will get stuck trying to get the release key with wget.

Aptitude should be configured with proper proxy settings during OS installation.

Example from /etc/wgetrc

https_proxy = <proper proxy server url>

http_proxy = <proper proxy server url>

ceph-deploy install --release dumpling <node01>...<nodexx>

Create Monitors

Add initial monitors and gather the keys.

ceph-deploy mon create-initial <monitor01>…<monitorxx>

Add OSDs

The typical manual flow for adding an OSD to the cluster with SSD journals is below, with the SSD as /dev/sdt and the OSD

on /dev/sda for the target host.

If there’s no partition table on the target journal SSD, create one.

ssh hp-osdhost01 sudo “parted -s /dev/sdt mklabel gpt”

Create partition on the target journal SSD.

ssh hp-osdhost01 -s mkpart cephjournal01 0G 4G

Create new partition table on the OSD. ceph-deploy has failed trying to clear a partition table when repurposing a drive; an

explicit redo of the table has proved more reliable.

ssh hp-osdhost01 sudo "parted -s /dev/sda mklabel gpt"

Prepare and activate the OSD (create command does both it in one step)

ceph-deploy --overwrite-conf osd create hp-osdhost01:sda:sdt1

The scripts below are simple examples for setting up all drives on a box in a batch. These are not robust (no real error

handling, output help, etc.) but can be a useful starting point for command syntax/function. All these scripts assume the

install instructions above such that no ssh password entry is necessary.

A more robust creation mechanism would probably leverage orchestrating software, but even with occasional hiccups the

scripts below generally suffice if adding new OSDs is not all that common of a task.

Sample script for creating SSD journal partitions, 4 per ssd interleave.

#!/bin/bash

tgtsys=${1}

if [ -z "${tgtsys}" ]; then

echo "No target system."

exit 1

tgtdrv=${2}

if [ -z "${tgtdrv}" ]; then

echo "No target disk."

exit 1
