Reference Architecture| Ceph on HP ProLiant SL4540 Gen8 Servers
Bill of materials
This BOM reproduces the sample reference configuration. Note: HP ProLiant servers ship with an IEC-IEC power cord for rack
mounting.
HP ProLiant SL4540 Gen8 Server
Qty Part Number Description
5 663600-B22 HP ProLiant SL454x 2x Node Chassis
10 664644-B22 HP 2xSL4540 Gen8 Tray Node Svr
10 684373-L21 HP SL4540 Gen8 Intel® Xeon® E5-2470 (2.3GHz/8-core/20MB/95W) FIO Processor Kit
60
647897-B21
HP 8GB (1x8GB) Dual Rank x4 PC3L-10600R (DDR3-1333) Registered CAS-9 Low
Voltage Memory Kit
10 664648-B21 HP SL4500 10GbE IO Module Kit
10 655874-B21 HP QSFP/SFP+ Adaptor Kit
10 692276-B21 HP Smart Array P420i Mezz Ctrllr FIO Kit
10 631679-B21 HP 1GB FBWC for P-Series Smart Array
10 668943-B21 HP 12in Super Cap for Smart Array
10 655708-B21 HP 500GB 6G SATA 7.2k 2.5in SC MDL HDD
200 652766-B21 HP 3TB 6G SAS 7.2k 3.5in MDL SC HDD
50 691864-B21 HP 200GB 6G SATA 2.5in SC Enterprise SSD
10 656364-B21 HP 1200W CS Platinum Power Supply kit
5 681254-B21 HP 4.3U Rail Kit
0 681260-B21 HP 0.66U Spacer Blank Kit—Available, but not used for this configuration.
10 512485-B21 HP iLO Adv 1-Svr incl 1yr TS&U SW
HP ProLiant DL360p Gen8 Server
Qty Part Number Description
3 654081-B21 HP ProLiant DL360p Gen8 8 SFF Server
3 654772-L21 HP DL360p Gen8 E5-2650 FIO Kit
3 654772-B21 HP DL360p Gen8 E5-2650 Kit
24 690802-B21 HP 8GB 2Rx4 PC3-12800R-11 Kit
3 684208-B21 HP Ethernet 1GbE 4P 331FLR FIO Adptr
3 665249-B21 HP Ethernet 10GbE 2P 560SFP+ Adptr
6 652572-B21 HP 450GB 6G SAS 10K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive
3 631679-B21 HP 1GB FBWC for P-Series Smart Array
3 339778-B21 HP Raid 1 Drive 1 FIO Setting
6 503296-B21 HP 460W CS Gold Ht Plg Pwr Supply Kit
3 663200-B21 HP 1U FIO Friction Rail Kit
3 512485-B21 HP iLO Adv 1-Svr incl 1yr TS&U SW
