HP ProLiant SL4540 Gen8 Server Node Maintenance and Service Guide

Illustrated parts catalog 18
Item Description Spare part
number
Customer self
repair (on
page
5
)
4
System boards — —
a) System board 687246-001 Optional
2
b) System board-IVB*
755313-001
Optional
2
5
Hot-plug solid state SATA drives — —
a) 100-GB, SFF, MLC, 3G 653965-001 Mandatory
1
b) 200-GB, SFF, MLC, 3G*
653966-001
Mandatory
1
c) 400-GB, SFF, MLC, 3G* 653967-001 Mandatory
1
d) 500-GB, SFF, MDL, 6G* 656107-001 Mandatory
1
e) 1-TB, SFF, MDL, 6G* 656108-001 Mandatory
1
Memory
6
DIMMs — —
a) 4-GB, PC3L-10600R-9, single-rank x4 664688-001 Mandatory
1
b) 8-GB, PC3L-10600R-9, dual-rank x4* 664690-001 Mandatory
1
c) 16-GB, PC3L-10600R-9, dual-rank x4* 664692-001 Mandatory
1
d) 8-GB, PC3L-12800R, single-rank x4* † 735302-001 Mandatory
1
e) 16-GB, PCL3-12800R, IPL 1Gx4* † 715284-001 Mandatory
1
f) 8-GB, PCL3-12800R, IPL 512Mx4* † 715283-001 Mandatory
1
g) 4-GB, PCL3-12800R, IPL 512Mx4* † 715282-001 Mandatory
1
h) 8-GB, PCL3-12800E, IPL 512Mx8* † 715281-001 Mandatory
1
i) 2-GB, PCL3-12800E, IPL 256Mx8* † 715279-001 Mandatory
1
j) 4-GB, PCL3-12800E, IPL 256Mx8* † 715208-001 Mandatory
1
7
Heatsink 689496-001 Optional
2
8
Personality board assembly 717703-001 Optional
2
9
SUV interface board 689237-001 Mandatory
1
10
Processors — —
a) 2.3-GHz Intel Xeon E5-2470 processor** 676943-001 Optional
2
b) 2.4GHz Intel Xeon E5-2440 processor* ** 676945-001 Optional
2
c) 2.2-GHz Intel Xeon E5-2430 processor* ** 676946-001 Optional
2
d) 2.2 GHz Intel Xeon E5-2407 processor* ** 676948-001 Optional
2
e) 2.0 GHz Intel Xeon E5-2430L processor* ** 676950-001 Optional
2
f) 2.4-GHz Intel Xeon E5-2470v2 processor* ** † 729115-001 Optional
2
g) 2.50-GHz Intel Xeon E5-2450 v2 processor* ** † 729114-001 Optional
2
h) 1.90-GHz Intel Xeon E5-2440 v2 processor* ** † 729113-001 Optional
2
i) 2.50-GHz Intel Xeon E5-2430 v2 processor* ** † 729112-001 Optional
2
j) 2.20-GHz Intel Xeon E5-2420 v2 processor* ** †
729111-001
Optional
2
