HP ProLiant SL170s G6 Server Software Configuration Guide

System BIOS configuration 17
IPMI Configuration submenu
Figure 11 IPMI Configuration submenu
Table 10
IPMI Configuration submenu fields
Field
Description
Lite Config L-Pro This option is for 60W processors with 2X4GB DIMMs per CPU and one SATA HDD.
The default setting is Disabled, when set to “Enabled”, system will load SDR for this
configuration.
Lite Config H-Pro This option is for 95W processors with 2X4GB DIMMs per CPU and one SATA HDD.
The default setting is Disabled, when set to “Enabled”, system will load SDR for this
configuration.
SEL Configuration S
elect SEL Configuration in the left frame of the screen to go to the submenu for that item.
Then you can press Enter to enter its submenu. You can display a submenu about SEL
Configuration option by highlighting it using the <Arrow> keys.
Serial Port
Configuration
Select Serial Port Configuration in the left frame of the screen to go to the submenu for
that item. Then you can press Enter to enter its submenu. You can display a submenu
about Serial Port Configuration option by highlighting it using the <Arrow> keys.
LAN Configuration Select LAN Configuration in the left frame of the screen to go to the submenu for that
item. You can display a submenu about LAN options by highlighting it using the<Arrow>
keys. Set LAN Setup options are described in this section. The Set LAN BIOS Setup
screen is shown below (When you have a LO100 Device, this item will display).
Watch Dog Timer
Reset
Select “Watch Dog Timer Reset “in the left frame of the screen and press<enter> to go to
the submenu for that item. That will display POST Watchdog Timer Action, BMC Watch
Dog Time Out; you can change the default value.
Hardware Health
Information
Select Hardware Health Information in the left frame of the screen and press<enter> to
go to the submenu for that item. That will display CPU temperature, ambient temperature,
CPU fan speed, system fan speed, chassis fan speed. These items cannot be changed by
the user. It accords with the sense of the case. If there is LV CPU and no card in slot1,
then System Fan 6 Rotor 1 and System Fan 6 Rotor 2 no display.
