ProLiant ML350 Generation 4 Reference and Troubleshooting Guide

Troubleshooting 149
Printer output is garbled
Action: Be sure the correct printer drivers are installed.
Mouse and Keyboard Problems
Action:
1. Be sure no loose connections (on page 129
) exist. If a KVM switching device
is in use, be sure the server is properly connected to the switch.
− For rack-mounted servers, check the cables to the switch box and be sure
the switch is correctly set for the server.
− For tower-model servers, check the cable connection from the input
device to the server.
2. If a KVM switching device is in use, be sure all cables and connectors are the
proper length and are supported by the switch. Refer to the switch
documentation.
3. Be sure the current drivers for the operating system are installed.
4. Be sure the device driver is not corrupted by replacing the driver.
5. Restart the system and check whether the input device functions correctly
after the server restarts.
6. Replace the device with a known working equivalent device (another similar
mouse or keyboard).
− If the problem still occurs with the new mouse or keyboard, the
connector port on the system I/O board is defective. Replace the board.
− If the problem no longer occurs, the original input device is defective.
Replace the device.
7. Be sure the keyboard or mouse is connected to the correct port. Determine
whether the keyboard lights flash at POST or the NumLock LED illuminates.
If not, change port connections.
8. Be sure the keyboard or mouse is clean.
Diagnostic Adapter Problems
NOTE: The Diagnostic Adapter is used only with ProLiant BL servers.
