50 HP ProLiant ML310 Generation 2 Server Maintenance and Service Guide
HP Insight Diagnostics
HP Insight Diagnostics is a proactive server management tool, available in both
offline and online versions, that provides diagnostics and troubleshooting
capabilities to assist IT administrators who verify server installations,
troubleshoot problems, and perform repair validation.
HP Insight Diagnostics Offline Edition performs various in-depth system and
component testing while the OS is not running. To run this utility, launch the
SmartStart CD.
HP Insight Diagnostics Online Edition is a web-based application that captures
system configuration and other related data needed for effective server
management. Available in Microsoft® Windows® and Linux versions, the utility
helps to ensure proper system operation.
For more information or to download the utility, refer to the HP website
(http://www.hp.com/servers/diags
).
Integrated Management Log
The IML records hundreds of events and stores them in an easy-to-view form.
The IML timestamps each event with 1-minute granularity.
You can view recorded events in the IML in several ways, including the
following:
• From within HP SIM ("HP Insight Diagnostics" on page 50
)
• From within Survey Utility (on page 49
)
• From within operating system-specific IML viewers
– For NetWare: IML Viewer
– For Windows®: IML Viewer
– For Linux: IML Viewer Application
• From within HP Insight Diagnostics ("Array Diagnostic Utility" on page 49
,
on page 50
)
