ProLiant ML310 Generation 2 Server Maintenance and Service Guide

Removal and replacement procedures 19
CAUTION: To prevent improper cooling and thermal damage, do
not operate the server unless all bays are populated with either a
component or a blank.
To remove the component:
1. Determine the status of the hard drive from the hot-plug hard drive LEDs
("Hot-plug SCSI hard drive LED combinations" on page 63
, "Hot-plug SCSI
hard drive LEDs" on page 62
).
IMPORTANT: When hot-plug SATA hard drives are installed,
SATA LED functionality and full SATA hot-plug capability are not
supported with the embedded controller. For full LED and hot-plug
support, an optional SATA RAID or SAS controller must be installed.
2. Unlock and open the bezel ("Unlocking the bezel" on page 16).
3. Remove the hard drive.
To replace the component:
1. Slide the drive into the cage until it clicks, locking the drive into place.
2. Close the lever.
IMPORTANT: When the drive is inserted, the drive LEDs flash for
2 seconds to indicate that the drive is seated properly and receiving
power.
