ProLiant DL740 Server Maintenance and Service Guide

About This Guide
Table 1: Location of Server Labels
Item Component Item Component
1 I/O board removal label 6 I/O board configuration label
2 Hot Plug RAID Memory cartridge
operation label
7 System board components label
3 System status LED indicators label 8 Rear connectors label
4 Removing power and media module
label
9 Removing host module label
5 Front components label
Related Documents
For additional information on the topics covered in this guide, refer to the following
documentation:
• Rack Resource Kits are included with the racks and include the following (depending on
rack model):
— Rack Products Documentation CD—Available on the HP website or included with
the Rack Resource Kit.
— 10000 Series Rack Resource Kit—Included with all HP 10000 Series racks.
— 9000 Series Products Audio-Visual (AV) CD Kit—Included with the Compaq
branded 9000 Series Rack Resource Kit.
— The Rack 7000/4000 Series Rack Resource Kit—Included with all Compaq branded
7000 and 4000 Series racks.
— Rack Builder Online—Available on the HP website. Instructions on how to access
and use this online tool are included in the Rack Resource Kit.
• Documentation included on the Documentation CD:
— Smart Array 5i Controller User Guide
— ROM-Based Setup Utility User Guide
— HP ProLiant Servers Troubleshooting Guide
— PCI Hot Plug Administration Guide
— Remote Insight Lights-Out Edition II User Guide
— Server Online Reference Guide
• ProLiant DL740 Power Calculator—Available on the ActiveAnswers website at
activeanswers.compaq.com/
