Host Module Removal and Replacement Procedures
4-4 HP ProLiant DL740 Server Maintenance and Service Guide
HP CONFIDENTIAL Codename: Jethro Part Number: 270853-004 Last Saved On: 2/13/04 10:40 AM
Processor Boards and Processors
Identifying
The ProLiant DL740 server is capable of supporting up to eight Intel® Xeon processors and
is shipped with four or eight processors already installed. The ProLiant DL740 server
supports two processor boards located in the host module.
Figure 4-3: Processor boards
Item Description
1 Processor board in processor board slot 1
2 Processor board in processor board slot 2
