Service Preparation
Table 2-1 describes the contents of the modules and how to access the components.
Table 2-1: Module Components and Access
Module Contents To Access
PCI Hot Plug expansion slots Open the top access panels.
Configuration switches Open the top access panels.
Fans 1 and 2 Open the top access panels.
Processor boards
Open the top access panels, open the
processor board cover, and remove the
processor boards.
Host module
Memory (DIMMs)
Open the top access panels and remove the
memory cartridge.
Power supply 1 and 2
Access directly at the front of the server.
Media bay
Access directly at the front of the server.
Power and
media module
Hot-plug hard drives Access directly at the front of the server.
Preparation Procedures
To access some components and perform certain service procedures, you must do one or
more of the following:
• Extend the server from the rack.
If you are performing service procedures in an HP rack or third-party rack cabinet, use
the locking feature of the rack rails to support the server and gain access to internal
components.
• Power down the server.
If you must remove a server from a rack or a non-hot-plug component from a server,
power down the server.
• Remove the server from the rack.
If the rack environment, cabling configuration, or server location in the rack creates
awkward conditions, remove the server from the rack.
