ProLiant DL740 Server Maintenance and Service Guide

Service Preparation
Server Modules
In the HP ProLiant DL740 server, options and accessories are easily accessed through top
access panels and two removable modules: the power and media module, and the host
module. See Figure 2-1, Figure 2-2, and Figure 2-3 for identification of these modules and
other components.
Figure 2-1: Server modules
Item Description
1 Power and media module
2 Host module
