Illustrated Parts Catalog
HP ProLiant DL740 Server Maintenance and Service Guide 1-7
HP CONFIDENTIAL Codename: RedStar Part Number: 270853-004 Last Saved On: 2/10/04 3:45 PM
Miscellaneous
Table 1-4: Miscellaneous Spare Parts List
Item Description Spare Part Number
Miscellaneous plastics*
a) Guide, card, processor
b) Puller assembly, PCI, LV
c) Receptacle, interconnect, AC
d) Guide, memory
e) Gear, rack, processor
f) Guide, fan
g) Lightpipe, fan
h) Divider, upper fan
i) Ejector, right
j) Ejector, left
k) Grill, exhaust, chassis rear
l) Retainer, cardguide, PCI, CBN (quantity 9)
m) Assembly, PCI latch and base, PCI, CBN
n) Baffle, power backplane
o) Assembly extraction tool
280624-001
LED display board 280616-001
Internal battery* 179322-001
Ethernet loopback RJ-45* 317465-001
Return kit* 333783-001
*Not shown
