ProLiant DL740 Server Maintenance and Service Guide

Illustrated Parts Catalog
Table 1-3: Host Module Spare Parts List
Item Description Spare Part Number
Host Module Components
1 Host module chassis
2 PCI-X Hot Plug switchboard with cable 280615-001
3 Processor board 314379-001
4 Processor board cover 320104-001
Processors
5 Processor (1.5 GHz with 1-MB cache), clip, and heatsink 319952-001
Processor (2.0 GHz with 1-MB cache), clip, and heatsink* 327839-001
Processor (2.0 GHz with 2-MB cache), clip, and heatsink* 319953-001
Processor (2.2 GHz with 2-MB cache), clip, and heatsink* 352311-001
Processor (2.5 GHz with 1-MB cache), clip, and heatsink* 327840-001
Processor (2.7 GHz with 2-MB cache), clip, and heatsink* 352312-001
Processor (2.8 GHz with 2-MB cache), clip, and heatsink* 327841-001
Processor (3.0 GHz with 4-MB cache), clip, and heatsink* 352313-001
Reserved
Memory
6 Hot-plug memory cartridge 280613-001
7 Memory module, 256MB, PC133, 128Mb, ECC SDRAM DIMM 159377-001
Memory module, 512MB, PC133, 256Mb, ECC SDRAM DIMM* 177628-001
Memory module, 1GB, PC133, 256Mb, LP, ECC SDRAM DIMM* 321851-001
Memory module, 2GB, PC133, 512Mb, ECC SDRAM DIMM* 321852-001
Miscellaneous
8 PCI-X slot board 280614-001
9 Array enabler board 122232-001
10 Hot-plug I/O fan 280619-001
Miscellaneous cables*
a) 3.5 in LNG, no twist
b) Power, 6.5 in
c) Hot-Plug, PCI
d) LED board, flex
e) Power switch
f) Cord, AC, 10 A, 9 ft
280623-001
*Not shown
