NC7781 PCI-X Gigabit Server Adapter
Table 8-10: NC7781 PCI-X Gigabit Server Adapter
Network interface 10Base-T/100Base-TX
Compatibility IEEE 802.3i, 802.3u, 802.3x, 802.3ab, 802.3ad compliant
PCI-X 1.0, PCI 2.2, ACPI v1.1a
Data path 64/133 MHz, compatible with 64/100, 64/66, 66/33, and
32/33
Bus architecture PCI-X bus mastering, compatible with existing PCI bus
architecture
Network transfer rate
10Base-T (half-duplex), 10Base-2 10 Mbps
10Base-T (full-duplex) 20 Mbps
100Base-TX (half-duplex) 100 Mbps
100Base-TX (full-duplex) 200 Mbps
1000Base-TX (half-duplex) 1000 Mbps
1000Base-TX (full-duplex) 2000 Mbps
Connector RJ-45
I/O address and interrupt Automatic configuration
Cable support Category 5 or higher UTP; up to 100 m (328 ft)
Operating system driver support Microsoft Windows Server 2003
Microsoft Windows 2000
Microsoft Windows NT 4.0
Novell NetWare Server 6
Caldera OpenUnix 8
