Physical, Operating, and Performance Specifications
Hot-Plug Ultra3 SCSI Hard Drives
Table 8-8: Hot-Plug Ultra3 SCSI Hard Drives
18.2-GB 36.4-GB 18.2-GB
Capacity 18209.3 MB 36419.3 MB 18209.3 MB
Height 1.0 in 1.0 in 1.0 in
Size 3.5 in 3.5 in 3.5 in
Interface Wide-Ultra3 SCSI Wide-Ultra3 SCSI Wide-Ultra3 SCSI
Transfer rate 160 MB/s 160 MB/s 160 MB/s
Seek time (typical, including setting)
Single track 0.8 ms 0.9 ms 0.7 ms
Average 5.2 ms 5.7 ms 3.9 ms
Full stroke 12.0 ms 12.0 ms 12.0 ms
Rotational speed 10,000 rpm 10,000 rpm 15,000 rpm
Physical configuration
Bytes/sector 512 512 512
Logical blocks 35,565,080 17,773,524 35,565,080
Operating temperature
10° to 35° C
(50° to 95° F)
10° to 35° C
(50° to 95° F)
10° to 35° C
(50° to 95° F)
HP ProLiant DL740 Server Maintenance and Service Guide 8-9
