Physical, Operating, and Performance Specifications
Table 8-6: 24X Max IDE CD-ROM Drive Specifications continued
Access times (typical)
Full stroke
200 ms
Random
100 ms
Cache/buffer 128 KB
Startup time (typical)
> 7 s
Stop time
> 4 s
Audio output level
Line out
0.7 VRMS at 47 Ohms
Headphone
0.6 VRMS at 32 Ohms (maximum width)
Laser parameters
Type
Semiconductor laser GaA1As
Wave length
780 +/- 25 nm
Divergence angle
53.5° +/- 1.5°
Output power
0.14 mW
Interface IDE (ATAPI)
HP ProLiant DL740 Server Maintenance and Service Guide 8-7
