Table Of Contents

Illustrated parts catalog 10

Item Description

Original

assembly part

number

Modified

assembly part

number

Original

spare part

number

Modified

spare part

number

Customer self

repair

—

g) 72-GB SAS

drive, 10,000 rpm

*

375696-002 — 376597-001 — Yes

—

h) 36-GB SAS

drive, 10,000 rpm

*

375696-001 — 376596-001 — Yes

—

i) 60-GB SATA

drive, 5,400 rpm

*

390158-001 — 382264-001 — Yes

— Memory — — — — —

17

DIMM, PC2-3200,

DDR2

— — — — —

— a) 512 MB *

345112-

051‡ See

requirement

345112-851

359241-

001‡ See

requirement

413384-001 Yes

— b) 1 GB *

345113-

051‡ See

requirement

345113-851

359242-

001‡ See

requirement

413385-001 Yes

—

c) 2 GB (single-

rank) *

345114-

061‡ See

requirement

345114-861

359243-

001‡ See

requirement

413386-001 Yes

—

d) 2 GB (dual-

rank) *

345114-

051‡ See

requirement

345114-851

378021-

001‡ See

requirement

413387-001 Yes

— e) 4 GB *

345115-

061‡ See

requirement

345115-861

379984-

001‡ See

requirement

413388-001 Yes

—

Processor

assemblies

— — — — —

18

Processor

assemblies

— — — — —

—

a) Intel® 3.33-

GHz Xeon™ 8 MB

*

376660-001 — 379982-001 — Yes

—

b) Intel® 3.00-

GHz Xeon™ 8 MB

*

376660-002 — 379981-001 — Yes

—

c) Intel® 2.83-

GHz Xeon™ 4 MB

*

376661-001 — 379980-001 — Yes

—

d) Intel® 3.66-

GHz Xeon™ 1 MB

*

376659-002 — 389027-001 — Yes

—

e) Intel® 3.16-

GHz Xeon™ 1 MB

*

376659-001 — 377840-001 — Yes

—

f) Intel® 2.66-GHz

Xeon™ 1 MBx2

dual core *

399752-001 — 399954-001 — Yes
