I/O fan bracket
These procedures apply to both the 6- and 12-fan configurations. If necessary, configuration-specific
illustrations are provided.
To remove the component:
1. Power down the server (on page 29).
2. Remove all power supplies ("Hot-plug power supply" on page 33).
3. Extend or remove the server from the rack ("Extend the server from the rack" on page 28, "Remove
the server from the rack" on page 30).
4. Remove the access panel ("Access panel" on page 31).
5. Remove the power supply cage assembly ("Power supply cage assembly" on page 38).
6. Remove the power supply backplane ("Power supply backplane" on page 60).
CAUTION: To prevent damage to the server or expansion boards, power down the server and
remove all AC power cords before removing or installing the PCI riser cage.
7. Remove the PCI riser cage ("PCI riser cage" on page 62).
8. Remove expansion boards from slots 1 and 2 ("Expansion board (slots 1 and 2)" on page 65).
9. Remove the battery pack ("Removing the battery pack" on page 40).
10. Remove the air baffle ("Air baffle" on page 41).
IMPORTANT: For this procedure, you do not need to remove the hot-plug fans from the
processor fan bracket. When reinstalling the processor fan bracket, press the top of each fan
to be sure it seats securely.
11. Remove the processor fan bracket ("Processor fan bracket" on page 42).
12. Remove the hot-plug fans from the I/O fan bracket ("Hot-plug fan" on page 37).
13. Remove all DIMMs ("DIMMs" on page 58).
14. Remove the PPMs ("PPM" on page 48).
15. Remove the system board ("System board" on page 68).
16. Remove the I/O fan bracket.
