HP ProLiant DL385 Generation 2 Server Maintenance and Service Guide

Illustrated parts catalog 23
Item Description Assembly
part number
Spare part
number
Customer
self repair
(on page 6)
30 CD-RW/DVD-ROM drive, slimline, 24X
(optional)*
383696-002 399959-001 Mandatory
1
31 DVD+R/RW drive, slimline, 8X* 395911-001 399402-001 Mandatory
1
Memory
32 DIMMs — — —
a) 512-MB, registered PC2-5300, single-rank
DIMM*
405474-051 430449-001 Mandatory
1
b) 1-GB, registered PC2-5300, single-rank
DIMM*
405475-051 430450-001 Mandatory
1
c) 2-GB, registered PC2-5300, dual-rank
DIMM*
405476-051 432668-001 Mandatory
1
d) 4-GB, registered PC2-5300, dual-rank
DIMM*
405477-061 432670-001 Mandatory
1
Cables
33 Miscellaneous cable kit* — 408795-001 Mandatory
1
a) Power cable, 10-pin 394038-001 — —
b) Systems Insight Display cable 219049-003 — —
34 SAS cable* 361316-010 408796-001 Mandatory
1
35 Data cable kit* — 408797-001 Mandatory
1
a) Fan board cable* 372616-002 — —
b) Media drive multibay cable* 356452-003 — —
36 AC power cord* 142263-001 142258-001 Mandatory
1
Rack mounting hardware
37 Rack mounting hardware kit* 360322-503 359254-001 Mandatory
1
Miscellaneous
38 Media drive ejector assembly* 394022-002 409007-001 Mandatory
1
39 Battery, 3.3-V, lithium* 166899-001 153099-001 Mandatory
1
40 DC power supply, 1200-W* 412837-001 419613-001 Mandatory
1
Options
41 SAS hot-plug hard drive* — — —
a) 36-GB, 10,000-rpm, 2.5-in 375859-B21 376596-001 Mandatory
1
b) 72-GB, 10,000-rpm, 2.5-in 375861-B21 376597-001 Mandatory
1
42 60-GB SFF SATA hard drive, 5,400-rpm, 1 yr
warranty*
379306-B21 382264-001 Mandatory
1
43 Smart Array E200 Controller* 012891-001 412799-001 Optional
2
44 Smart Array E200 Controller cache module,
64-MB*
012970-001 412800-001 Optional
2
