Illustrated parts catalog 22
Item Description Assembly
part number
Spare part
number
Customer
self repair
(on page 6)
b) PCI riser cage, with non-hot-plug PCI-X/PCIe
(optional)*
412878-002 408788-001 Optional
2
c) PCI riser cage, with non-hot-plug PCIe
(optional)*
412878-003 430442-001 Optional
2
19 Processor — — —
a) 1.8-GHz, dual-core AMD Opteron™ Model
2210 HE, 68-W **
410714-004 434949-001 Optional
2
b) 1.8-GHz, dual-core AMD Opteron™ Model
2210, 95-W* **
410713-005 419473-001 Optional
2
c) 2.0-GHz, dual-core AMD Opteron™ Model
2212 HE, 68-W* **
410714-003 419475-001 Optional
2
d) 2.2-GHz, dual-core AMD Opteron™ Model
2214 HE, 68-W* **
410714-002 419477-001 Optional
2
e) 2.4-GHz, dual-core AMD Opteron™ Model
2216 HE, 68-W* **
410714-001 419479-001 Optional
2
f) 2.4-GHz, dual-core AMD Opteron™ Model
2216, 95-W* **
410713-002 419478-001 Optional
2
g) 2.6-GHz, dual-core AMD Opteron™ Model
2218 HE, 68-W* **
410714-005 439750-001 Optional
2
h) 2.6-GHz, dual-core AMD Opteron™ Model
2218, 95-W* **
410713-001 419480-001 Optional
2
i) 2.8-GHz, dual-core AMD Opteron™ Model
2220, 95-W* **
410713-006 439749-001 Optional
2
j) 3.0-GHz, dual-core AMD Opteron™ Model
2222, 95-W* **
410713-007 451810-001 Optional
2
20 Processor heatsink, thermal grease, and alcohol
pad
391137-001 408790-001 Optional
2
Boards
21 PPM 399854-001 407748-001 Mandatory
1
22 System board with backplate and battery — 430447-001 Optional
2
23 Power supply backplane 399428-001 407750-001 Mandatory
1
24 8-bay hard drive backplane 012531-001 407751-001 Mandatory
1
25 Fan board — — —
a) Fan board, 12-fan model 012525-001 408791-001 Optional
2
b) Fan board, 6-fan model* 012525-001 442955-001 Optional
2
26 Systems Insight Display with cover 406566-001 430448-001 Mandatory
1
Media drives
27 USB diskette drive (optional) 359098-003 391091-001 Mandatory
1
28 CD-ROM drive, removable slimline (optional)* 222837-003 399401-001 Mandatory
1
29 DVD-ROM drive, removable slimline, 8X/24X
(optional) *
395910-001 397928-001 Mandatory
1
