HP ProLiant DL385 Generation 2 Server Maintenance and Service Guide

Illustrated parts catalog 18
Item Description Assembly
part number
Spare part
number
Customer
self repair
(on page 6)
3 Hard drive blank 376383-001 392613-001 Mandatory
1
4 Media drive blank 377569-001 409006-001 Mandatory
1
5 Power supply cage assembly 394020-001 408785-001 Mandatory
1
6 Power supply blank 394436-001 409417-001 Mandatory
1
7 Air baffle — — —
a) Air baffle, 12-fan model 404847-001 430441-001 Mandatory
1
b) Air baffle, 6-fan model* 440933-001 442957-001 Mandatory
1
8 Processor fan bracket — — —
a) Processor fan bracket, 12-fan model 394023-002 408783-001 Mandatory
1
b) Processor fan bracket, 6-fan model* 441011-001 442953-001 Mandatory
1
9 Processor fan bracket plate 419341-002 430371-001 Mandatory
1
10 I/O fan bracket — — —
a) I/O fan bracket, 12-fan model 419315-001 408784-001 Mandatory
1
b) I/O fan bracket, 6-fan model* 441015-001 442954-001 Optional
2
11 Hardware kit* — 407752-001 Mandatory
1
a) Retainer spring 397450-001 — —
b) Screws, 6-32 × 0.200-in Torx, hi-top (4)
(media drive ejector assembly, media drive
cable, external option blank)
192308-009 — —
c) Hard drive cage screws, 6-32 × 0.125-
in, T-15 Torx, (2)
242966-006 — —
d) Front bezel screws, T-15, flat-head (2) 228213-003 — —
e) Expansion slot cover, short 394041-001 — —
f) Thumbscrew, molded cap 179333-003 — —
g) Thumbscrew assembly, right-attach 405895-002 — —
h) Thumbscrew assembly, left-attach 405895-001 — —
12 Misc. rubber grommet isolation kit* — 430370-001 Mandatory
1
13 Plastics kit* — 407753-001 Mandatory
1
a) PPM retainer (2) 390534-001 — —
b) PCI retainer, low profile (2) 397873-001 — —
c) Hard drive backplane retainer 397449-001 — —
d) T-10/T-15 Torx screwdriver holder 373134-001 — —
e) PCI card guide retainer 379046-002 — —
f) Power cord retainer clip 352993-001 — —
14 Return kit, pack box, and cushions* — 289545-001 Mandatory
1
15 T-10/T-15 Torx screwdriver* 377511-001 413965-001 Mandatory
1
