Component identification 15
Systems Insight Display
LED and color
Health LED
System power
LED
Status
Power cap (flashing
amber)
— Amber Power cap has been exceeded.
Power cap (green)
— Green Power is available.
IMPORTANT:
If more than one DIMM slot LED is illuminated, further troubleshooting is required.
Test each bank of DIMMs by removing all other DIMMs. Isolate the failed DIMM by replacing
each DIMM in a bank with a known working DIMM.
SAS and SATA device numbers
• Four hard drive configuration
• Eight hard drive configuration
