Server component identification 9
Item Description Status
3 NIC 1 link/activity LED Green = Network link exists.
Flashing green = Network link and activity exist.
Off = No link to network exists.
If power is off, view the LEDs on the RJ-45 connector for status
by referring to the rear panel LEDs ("Rear panel LEDs and
buttons" on page 11).
4 NIC 2 link/activity LED Green = Network link exists.
Flashing green = Network link and activity exist.
Off = No link to network exists.
If power is off, the front panel LED is not active. View the LEDs
on the RJ-45 connector for status by referring to the rear panel
LEDs ("Rear panel LEDs and buttons" on page 11).
5 Drive activity LED Green = Drive activity is normal.
Amber = Drive failure occurred.
Off = No drive activity.
6 Power On/Standby button
and system power LED
Green = System is on.
Amber = System is shut down, but power is still applied.
Off = Power cord is not attached, power supply failure has
occurred, no power supplies are installed, facility power is not
available, or the DC-to-DC converter is not installed.
