HP ProLiant BL620c G7 Server Blade Maintenance and Service Guide

Illustrated parts catalog 19
Item Description
Spare part
number
Customer self repair
(on page
5
)
a) HP 4X QDR IB Mezzanine HCA for HP
BladeSystem c-Class
583999-001 Mandatory
1
b) HP 4X DDR IB, CX-
2, Dual Port Mezzanine HCA
for HP BladeSystem c-Class
593411-001 Mandatory
1
c) HP 4X PCIe Mezzanine HCA for HP BladeSystem
c-Class
436010-001 Mandatory
1
17
Storage controller — —
a) Cache module, 512-MB 462975-001 Mandatory
1
b) BBWC battery pack 462976-001 Mandatory
1
c) Battery cable, 71 cm (28 in)* 488137-001 Mandatory
1
d) Cache module, 512-MB, flashback* 578882-001 Mandatory
1
e) Cache module, 1-GB, flashback* 505908-001 Mandatory
1
f) Supercap module assembly* 587324-001 Mandatory
1
g) Cache module, BBWC, DDR2, 512-MB* 451792-001 Mandatory
1
h) RAID contoller, SAS, BladeSystem* 510026-001 Mandatory
1
i) Battery cable, 29 cm (11.5 in), 16-pin* 409124-001 Mandatory
1
j) Battery module, V500HTX, low power* 453779-001 Mandatory
1
k) Smart Array controller, 6G 537156-001 Mandatory
1
18
Server blade release lever kit* 531232-001 Optional
2
a) Server blade release lever — —
b) Server blade release button — —
c) Server blade release lever spring — —
d) Server blade release lever nut — —
19
Cable kit* 610099-001 Mandatory
1
a) SAS signal cable — —
b) SAS power cable — —
*Not shown
**Do not mix processors with different speeds or cache sizes.
1
Mandatory—Parts for which customer self repair is mandatory. If you request HP to replace these parts, you will be
charged for the travel and labor costs of this service.
2
Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If,
however, you require that HP replace them for you, there may or may not be additional charges, depending on the type
of warranty service designated for your product.
3
No—Some HP parts are not designed for customer self repair. In order to satisfy the customer warranty, HP requires that
an authorized service provider replace the part. These parts are identified as "No" in the Illustrated Parts Catalog.
1
Mandatory: Obligatoire—Pièces pour lesquelles la réparation par le client est obligatoire. Si vous demandez à HP de
remplacer ces pièces, les coûts de déplacement et main d'œuvre du service vous seront facturés.
2
Optional: Facultatif—Pièces pour lesquelles la réparation par le client est facultative. Ces pièces sont également
conçues pour permettre au client d'effectuer lui-même la réparation. Toutefois, si vous demandez à HP de remplacer ces
pièces, l'intervention peut ou non vous être facturée, selon le type de garantie applicable à votre produit.
