Illustrated parts catalog 17
Item Description
Spare part
number
Customer self repair
(on page
5
)
a) 2.27-GHz Intel® Xeon® X7560 processor ** 594893-001 Optional
2
b) 2.0-GHz Intel® Xeon® X6550 processor* ** 594896-001 Optional
2
c) 1.86-GHz Intel® Xeon® L7555 processor* ** 594900-001 Optional
2
d) 1.86-GHz Intel® Xeon® E7530 processor* ** 594898-001 Optional
2
e) 2.0-GHz Intel® Xeon® E6540 processor* ** 594899-001 Optional
2
f) 1.73-GHz Intel® Xeon® E6510 processor* ** 594901-001 Optional
2
g) 2.40-GHz Intel® Xeon® E7-2870 processor*
**
650014-001 Optional
2
h) 2.26-GHz Intel® Xeon® E7-2860 processor*
**
650015-001 Optional
2
i) 2.0-GHz Intel® Xeon® E7-2850 processor* ** 650016-001 Optional
2
j) 2.13-GHz Intel® Xeon® E7-2830 processor* **
650017-001 Optional
2
k) 2.0-GHz Intel® Xeon® E7-2820 processor* ** 650018-001 Optional
2
l) 1.73-GHz Intel® Xeon® E7-2803 processor* **
650019-001 Optional
2
m) 2.13-GHz Intel® Xeon® E7-8867L processor*
**
653056-001 Optional
2
6
Heatsink 610098-001 Optional
2
7
Hard drives — —
a) 600-GB, SAS, SFF, 10,000-rpm, 6G 581311-001 Mandatory
1
b) 450-GB, SAS, SFF, 10,000-rpm, 6G* 581310-001 Mandatory
1
c) 300-GB, SAS, SFF, 10,000-rpm, dual-port, 6G*
616671-001 Mandatory
1
d) 146-GB, SAS, SFF, 15,000-rpm, dual-port, 6G*
512744-001 Mandatory
1
e) 72-GB, SAS, SFF, 15,000-rpm, dual-port, 6G* 512743-001 Mandatory
1
f) 500-GB, SAS, SFF, 7,200-rpm, 6G* 508009-001 Mandatory
1
g) 500-GB, SATA, SFF, 7,200-rpm* 508035-001 Mandatory
1
h) 160-GB, SATA, SFF, 7,200-rpm, 3G* 530932-001 Mandatory
1
i) 120-GB, SATA, SFF, SSD* 572253-001 Mandatory
1
j) 60-GB, SATA, SFF, SSD* 572252-001 Mandatory
1
k) 1-TB, SAS, 7,200-rpm, 6G* 606020-001 Mandatory
1
l) 1-TB, SATA, SFF, 7,200-rpm, 3G* 626162-001 Mandatory
1
m) 250-GB, SATA, SFF, 7,200-rpm, 3G* 626161-001 Mandatory
1
8
DIMMs — —
a) PC3-10600R 2-GB, DDR3-1333, 128-MB x8 501533-001 Mandatory
1
b) PC3-10600R 4-GB, DDR3-1333, 256-MB x4* 501534-001 Mandatory
1
c) PC3-10600R 8-GB, DDR3-1333, 512-MB x4* 501536-001 Mandatory
1
d) PC3-10600R 16-GB, DDR3-1333, 512-MB x4*
501538-001 Mandatory
1
e) PC3L-10600R 8-GB DDR3-1333, 512-MB x4* 606427-001 Mandatory
1
