ProLiant BL35p Server Blade Maintenance and Service Guide

Table Of Contents

Illustrated parts catalog 7

Spare parts list (ATA models)

NOTE: Always retain the server blade handle. The handle contains a serial number that

maintains the original server blade warranty.

Item Description Spare part

number

Customer

replaceable?

Mechanical components

1 System board assembly,

with two single-core heatsinks, two dual-core heatsinks,

and LED board

381803-001 Yes

System components

2 Processor — —

a) 2.4-GHz AMD Opteron™ single-core 381836-001 Yes

b) 1.8-GHz AMD Opteron™ dual-core 395083-001 Yes

c) 2.0-GHz AMD Opteron™ dual-core 395084-001 Yes

d) 2.2-GHz AMD Opteron™ dual-core 395085-001 Yes

e) 2.4-GHz AMD Opteron™ dual-core 414452-001 Yes

3 Fan assembly 361748-001 Yes

4 NIC riser board, mezzanine 361745-001 Yes

5 Power converter module 361752-001 Yes

Memory

6 DIMMs — —

a) DIMM, 512-MB, PC3200 DDR 400-MHz SDRAM 381817-001 Yes

b) DIMM, 1-GB, PC3200 DDR 400-MHz SDRAM 381818-001 Yes

c) DIMM, 2-GB, PC3200 DDR 400-MHz SDRAM 381819-001 Yes

d) DIMM, 4-GB, PC2700 DDR 333-MHz SDRAM 416258-001 Yes

Miscellaneous

7 Heatsinks — —

a) Heatsink, single-core processor 381804-001 Yes

b) Heatsink, dual-core processor 396768-001 Yes

8 Dual Port Fibre Channel Adapters (2 GB) — —

a) QLogic-based Dual Port Fibre Channel Adapter (2-GB) 361744-001 Yes

b) Emulex-based Dual Port Fibre Channel Adapter (2-

GB)*

399852-001 Yes

9 Hard drive, 60-GB, ATA 361751-001 Yes

10 Hardware kit 361750-001 Yes

a) 3U server blade blank — —

b) Drive cage assembly — —

11 HP BladeSystem p-Class sleeve access panel 361881-001 Yes
