Component identification 35
Item Description Status
4 NIC 2 LED* Green = Network linked
Green flashing = Network activity
Off = No link or activity
5 Hard drive activity LED Green/Flashing = Activity
Off = No activity
6 Power On/Standby button
LED
Green = On
Amber = Standby (auxiliary power
available)
Off = Off
7 Local I/O port** —
* Actual NIC numeration depends on several factors, including the operating system installed on the server blade.
** The Local I/O port is used with the local I/O cable for local management and for connecting external devices to
the server blade, such as USB keyboard, USB mouse, video monitor, USB diskette drive, and USB CD-ROM drive.
