Removal and replacement procedures 22
CAUTION: Be sure that the processor socket locking lever is closed after the processor is
installed. The lever should close without resistance. Forcing the lever closed can damage the
processor and socket, requiring system board replacement.
2. Close the processor locking lever.
3. Remove the protective cover from the thermal interface.
