Illustrated parts catalog 10
Item Description Spare part
number
Customer
replaceable?
7 Heatsink, dual-core processor 396768-001 Yes
8 SAS controller 403624-001 Yes
9 Hard drives — —
a) 36-GB SAS 404784-001 Yes
b) 72-GB SAS 404785-001 Yes
c) 146-GB SAS 437862-001 Yes
10 Hardware kit 404678-001 Yes
a) 3U server blade blank — —
b) Drive cage assembly * — —
c) Latch release, spring, and screw * — —
11 HP BladeSystem p-Class sleeve access panel 361881-001 Yes
12 HP BladeSystem p-Class sleeve board 361746-001 Yes
13 Air baffle (dual-core processor systems only) 398028-001 Yes
14 Cable kit * 403623-001 Yes
a) Power button/LED cable — —
b) Hard drive cable — —
15 Replacement battery, 3-V lithium * 234556-001 Yes
16 Local I/O cable * 355935-001 Yes
*Not shown
