Cabling 49
2.
Connect the video connector to a monitor.
3. Connect a USB hub to one USB connector.
4. Connect the following to the USB hub:
o USB CD/DVD-ROM drive
o USB keyboard
o USB mouse
o USB diskette
Item Description
1 Monitor
2 USB mouse
3 HP c-Class Blade SUV Cable
4 Server blade
5 USB hub
6 USB keyboard
7 USB CD/DVD-ROM drive or diskette drive
