HP ProLiant BL260c Generation 5 Server Blade Maintenance and Service Guide

Illustrated parts catalog 18
Item Description Spare part number Customer self repair
(on page 5)
p) 1.86-GHz Intel® Core™ 2 Duo processor
E6305, quad-core, uni-processor, 2-MB L2 cache,
1066-MHz FSB* **
469659-001 Optional
2
q) 2.13-GHz Intel® Core™ 2 Duo processor
E6405, dual-core, uni-processor, 2-MB L2 cache,
1066-MHz FSB* **
469658-001 Optional
2
r) 2.66-GHz Intel® Xeon® processor L5430,
quad-core, 2x6-MB L2 cache, 1333-MHz FSB*
**
459735-001 Optional
2
5 Heatsink 468916-001 Optional
2
6 120-GB, SATA hard drive, non-hot-plug, SFF,
5,400-rpm
459616-001 Mandatory
1
Boards
7 DIMMs — —
a) 1-GB, PC2-5300 416356-001 Mandatory
1
b) 1-GB, PC2-5300, low-power, RoHS* 488608-001 Mandatory
1
c) 2-GB, PC2-5300* 432668-001 Mandatory
1
d) 2-GB, PC2-5300, low-power, RoHS* 416357-001 Mandatory
1
e) 4-GB, PC2-5300* 432670-001 Mandatory
1
f) 4-GB, PC2-5300, low-power, RoHS* 487945-001 Mandatory
1
g) 8-GB, PC2-5300* 432671-001 Mandatory
1
8 System board 468915-001 Optional
2
Miscellaneous
9 System battery* 234556-001 Mandatory
1
10 Mezzanine card options* — —
a) Emulex LPe1105-HP 4Gb FC HBA for HP c-
Class BladeSystem
405921-001 Mandatory
1
b) QLogic QMH2462 4Gb FC HBA for HP c-
Class BladeSystem
405920-001 Mandatory
1
c) HP 4X DDR IB Mezzanine HCA for HP
BladeSystem c-Class
410500-001 Mandatory
1
d) HP NC325m PCI Express Quad Port Gigabit
Server Adapter for c-Class BladeSystem
436011-001 Mandatory
1
e) HP NC326m PCI Express Dual Port 1Gb Server
Adapter for c-Class BladeSystem
419330-001 Mandatory
1
f) HP NC360m Dual Port 1GbE BL-c Adapter 448068-001 Mandatory
1
g) HP NC364m Quad Port 1GbE BL-c Adapter 448066-001 Mandatory
1
h) HP NC373m PCI Express Dual Port
Multifunction Gigabit Server Adapter for c-Class
BladeSystem
430548-001 Mandatory
1
