b. Ensure that the Enable Switch Binding check box is checked (enabled).
c. Select the Restrict E_Ports radio button to restrict connections from
specific fabric elements to E_Ports. WWNs can be added to the
membership list to allow fabric element connection and removed from the
list to prohibit fabric element connection. Devices are allowed to connect
to any F_Port or FL_Port without restriction.
d. Click Activate to close the dialog box and enforce the connection policy.
9. Update channel path and control unit definitions — A cascaded FICON
environment requires channel entry switch and link address updates to the
input/output configuration program (IOCP) as follows:
a. In the IOCP, define an entry switch ID in the SWITCH keyword of the
channel path identifier (CHPID) definition.
Note: An entry switch is a fabric director or switch connected to the FICON channel
of a zSeries processor and a second fabric director or switch.
b. In the IOCP, define a 2-byte link address (consisting of a switch (or
domain) address and port address) for the cascaded switch in the LINK
keyword of the control unit (CNTLUNIT) definition.
Note: An cascaded switch is a fabric director or switch connected to a destination
control unit and an entry switch.
c. Run the IOCP to create an input/output configuration data
set (IOCDS). The switch ID (CHPID macroinstructions) and 2-byte link
address (control unit macroinstructions) are updated in the IOCDS.
Refer to the IBM FICON Native Implementation and Reference Guide
(SG24-6266) for additional information.
10. Verify FICON devices log back in — Inspect the Node List View
(Figure 51) and verify FICON devices (channels and control units inspected
in step 5) log back in to the fabric as expected.
11. Verify cascaded FICON operation — Verify operation of established
logical FICON paths between channels and control units, and verify that
cascaded FICON traffic is transmitted through the fabric as expected.
