How to perform unattended NOS installation Using HP Toptools Remote Control

8
• For NT4, you must now complete the driver information on disk 5 in the following files:
\srvtype\lhx\
nt4srv.inf
txtsetup.oem
• On disk 5, edit the file:
Autoexe.bat
- You must enter the name of the server that will contain the shared file - ECHO SET
NETSERVER=e800-TTDM>> A:\VARS.BAT.
- You have just created a shared file with the following name:
■■
NT4SRV. If you have used a different name, change at this line:
ECHO SET NETSHARE=NT4SRV>> A:\VARS.BAT
2. Creating a *.dsk file from the Navigator CD
• Go to the copydisk.exe utility, located on the HP Netserver Navigator CD under TTRC
To create a disk image (*.dsk) of your disk and to copy it to the directory, please follow these steps:
• Open a MS DOS window
• Launch copydisk.exe using this syntax:
Copydisk sourcedrive destinationpath
where “sourcedrive” is a floppy disk drive on your PC that you would like to convert to a *.dsk
file (e.g. A:\ ) and “destinationpath” is the destination drive.
3. Configuring a TFTP server to communicate with the TT_RCC
To start the supplied TFTP server, the program “tftpserv.exe” must be executed on the server in a DOS
window or using the Run command from the Windows Start menu:
tftpserv.exe [root]
where [root] indicates the base directory from which a client can retrieve files. If the root is not
specified, the current working directory is used as the base directory.
If you have already installed the Toptools Device Manager on one of your machines, that machine
will automatically become a TFTP server. The directory from which a client can retrieve files is:
\program files\hptt\data\packages\
A TFTP client can request files within the base directory or its subdirectories but does not have access
to lower directories. The server software enables the base directory to act only as a file source, not
as a file destination.
• Insert the Navigator CD into the client.
•Click Exit to close the Disk Library or Netserver Navigator screen.
• Create a c:\tftp directory.
• Using Explorer, navigate to and view the CDROM:\ttrc\us directory.
• Copy the following file into the root of the C drive:
tftpserv.exe (the executable program)
refer to software scripts:
\\unattended install
\disk 5
refer to software scripts:
\\unattended install
\disk 5
