Managed Systems Configuration Guide

Chapter 12: HP-UX Server Configuration

installing SFM version A.04.00.xx.

l The items in this table are listed in the sequence in which they should be installed in case any of

them are missing and require upgrade or installation.

Required Software Version Required

HP-UX Operating Environment 11i v1

How to Download or Access Software:

http://h20338.www2.hp.com/hpux11i/cache/324916-0-0-0-121.html

Operating System Patch Requirements Any 11i v1 OE is supported, however any 11i v1 OE

prior to June, 2003, must also have patch bundle

B.11.11.0306.1 installed.

How to Download Patches for HP-UX:

Go to

http://itrc.hp.com/service/patch/hpuxPatchBundlePage.do?bundleId=BUNDLE11i:B.11.11.0306.1

OpenSSL A.00.09.07i.012 product bundle (December, 2006)

or later

How to Download or Access Software:

l Available on Application Software Media from December, 2006 onwards

l Alternatively, go to the following HP Software Depot location for the latest version:

https://h20392.www2.hp.com/portal/swdepot/try.do?productNumber=OPENSSL11I

WBEMServices (WBEM Services Core Product) A.02.05 product bundle (December, 2006) or later

How to Download or Access Software:

l Available on Application Software Media from December 2006 onwards

l Alternatively, go to the following HP Software Depot location for the latest version:

https://h20392.www2.hp.com/portal/swdepot/try.do?productNumber=WBEMSvcs

Online Diagnostics B.11.11.18.05 Support Tools Bundle (December,

2006)

How to Download or Access Software:

l Available on HWE0612 media

l Alternatively, go to the following HP Software Depot location for the latest version:

https://h20392.www2.hp.com/portal/swdepot/try.do?productNumber=B6191AAE

Table 12.1 Required Software Components for HP-UX 11i v1

HP Insight Remote Support Advanced (A.05.80)Page 71 of 204
