Chapter 8
Integrity Windows 2003 Server Configuration
This chapter applies only to Windows 2003 Integrity managed systems. Event Log Monitoring Collector
(ELMC) is responsible for remote support monitoring on Windows 2003 Integrity managed systems.
SNMP is necessary for Discovery, and WBEM is necessary for Remote Data Collections. Before you can
monitor your Integrity Windows 2003 managed systems you must:
l Verify the managed systems are supported by checking the Insight Remote Support Advanced
Release Notes.
l Verify that ELMC is installed and configured.
l Verify that SNMP and WBEM are installed and configured. To determine which version of SNMP
Agents and WBEM Providers your managed systems require, consult the support matrix at the
following URL: http://h20338.www2.hp.com/integrity/w1/en/os/windows-on-integrity-releases.html.
l Verify connectivity from the managed systems to the CMS.
Fulfilling ELMC Requirements
The managed system must meet the following basic requirements before you install ELMC:
l Processor architecture: Itanium on Integrity Servers
l Operating system: On Integrity Servers, all supported versions of Windows 2003
l TCP-IP configured on the managed server
l Required Permissions and Access: To install, upgrade, or uninstall WEBES or the ELMC component,
you must be logged on as the Administrator or as a user with administrator privileges.
Installing the ELMC Software Package on the
Managed System
Copy the appropriate (IA64 or x86/x64) ELMC client from the RSSWM download folder on the CMS into a
temporary directory. Double click the installer file to begin the install process. The kit will install and finish
with no user prompting, for example there is no user configuration input required for this software package.
Verifying SNMP Agent Prerequisites on the
Managed System
For your Windows 2003 Integrity managed system to be discovered by HP SIM, you must have HP
Integrity SNMP Agents for Windows Server 2003 installed and fully configured on your managed systems
as directed in the HP SmartSetup product documentation for the appropriate package.
Note: WBEM Providers can coexist with SNMP Agents on the managed system system as long as
they have the same version number. Mismatched versions of HP Insight Management WBEM
