Chapter 7

ProLiant c-Class BladeSystem Enclosure

Configuration

Prerequisites

l Verify the managed systems are supported by checking the Insight Remote Support Advanced

Release Notes.

l Configure SNMP.

l Discover the monitored device.

l Verify connectivity from the managed systems to the CMS.

Important: The OA can only be configured to point to one Insight Remote Support Advanced CMS for

both SNMP and service event submissions. The OA cannot be set up to send SNMP traps to one

CMS and service events to another CMS. This is an unsupported configuration.

Configuring SNMP on the ProLiant c-Class

BladeSystem Enclosure

1. In a Web browser, open the HP BladeSystem Onboard Administrator.

2. In the log on screen, enter your user name and password and click Sign In.

3. Expand Enclosure Information → Enclosure Settings.

4. Click SNMP Settings.

HP Insight Remote Support Advanced (A.05.80)Page 49 of 204
