Managed Systems Configuration Guide
Chapter 6: Proliant Citrix Server Configuration
Installing System Management Homepage
System Management Homepage (SMH) is also included in the HP SNMP Agents for Citrix XenServer
software package. It provides additional reporting capabilities on the managed system itself. While not
mandatory for Insight Remote Support Advanced, if you configure SNMP services incorrectly to
communicate with the CMS during SNMP Agent installation you will need SMH to reconfigure those
settings.
Note: SMH is installed by default on the CMS with the Insight Remote Support Advanced solution.
Configuring SNMP
SNMP Agents are required for Citrix managed systems. Once you have installed the SNMP Agents on
your managed systems, access the snmpd.conf file to add the IP address for the CMS for SNMP
communication from the managed system(s). You will need to do this for each Citrix managed system.
1. In a Web browser, access the System Management Homepage (SMH) on the managed system:
https://ipaddress:2381.
2. Log on using the managed system root user name and password.
3. Click the Settings tab.
4. Click the SNMP Configuration link.
5. In the SNMP Configuration File add a trapsink command that includes the CMS IP address, for
example trapsink 1.2.3.4 public, and click Change.
HP Insight Remote Support Advanced (A.05.80)Page 45 of 204
